115 HO

PERFORMANCE TO THE MAX

THE H.O. SERIES. BLURRING THE LINE BETWEEN BOATING AND AVIATION. Like pushing limits? Then take a closer look at our High Output Series. Because they push limits about as far as they can go – and come with everything it takes to handle it.

The outboard of the future.

Introducing a revolutionary concept in outboards – a choice. Now, choose cutting-edge over commonplace. Choose more torque over more talk. Choose more time on the water over more time in the shop. Choose the outboard that performs, and looks like no other outboard in the world.

115 HO - Model-specific elements

SPECIFICATIONS

Model Weight Shaft Length
K115HGLF 415lbz / 188kgs 20" / 508mm
Color Slate Gray
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls
Steering iSteer DPS
K115HGLP 390lbs / 177kgs 20" / 508mm
Color Slate Gray- with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering Remote
K115HGXC‡ 401lbs / 182kgs 25" / 635mm
Color Slate Gray- with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering Remote / Tiebar
K115HGXF 426lbs / 193kgs 25" / 635mm
Color Slate Gray- with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering iSteer DPS
K115HGXP 401lbs / 182kgs 25" / 635mm
Color Slate Gray
Model Gear Ratio
Starting Method
Trim Method
Trim Range
Tilt Range
Counter Rotation
Controls
Steering Remote
K115HWLF 415lbz / 188kgs 20" / 635mm
Color Classic White - with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering iSteer DPS
K115HWLP 390lbs / 177kgs 20" / 508mm
Color Classic White - with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering Remote
K115HWXC‡ 401lbs / 182kgs 25" / 635mm
Color Classic White - with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering Remote / tiebar
K115HWXF† 426lbs / 193kgs 25" / 635mm
Color Classic White - with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering iSteer DPS
K115HWXP 401lbs / 182kgs 25" / 635mm
Color Classic White - with over 400 Color Panel Options
Model Gear Ratio 2.08:1
Starting Method Electric
Trim Method Power Trim & Tilt
Trim Range -6° to 15°
Tilt Range 81°
Counter Rotation
Controls ICON II
Steering Remote

Common Elements

Limited Warranty 5 Year
Engine type H.O. Inline 3-Cylinder E-TEC G2 D.I.
Displacement 114cu in / 1.9L
Recommended fuel 87 Octane
Emissions compliance EPA 2013 CARB 3 STAR European Union
Recommended Oil XPS Marine XD100
Oil Tank capacity 1.9 (7.2)
Full Throttle RPM Range 5000-6000 RPM
Alternator output Net Amps 14 idle / 22 wot
Fuel induction E-TEC Direct Injection with stratified low RPM combustion mode
Lubrication Multi-Point Targeted Oiling
Bore x Stroke 3.85" x 3.25" (98mm x 82.6mm)
Mounting Centers Minimum 26 (660)
Integrated Features Dual Axis Rigging / iTrim
Controls ICON II
